ASME U Stamp Certified 2 Pass TEMA Exchanger U-Bend Design for Thermal Expansion Resistance

Place of Origin: CHINA
Brand Name: YUHONG
Certification: ASME VIII Div. 1, PED/97/23/CE, TEMA R, TEMA C, TEMA B
Model Number: SHELL AND TUBE HEAT EXCHANGER
Minimum Order Quantity: 1 SET
Price: Depend on drawing
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Delivery Time: 20-80 days
Payment Terms: T/T, L/C, D/A
Supply Ability: 60 SETS/MONTH
Inquiry Now
Get A Quote
Specifications
Highlight Features

2 Pass Shell And Tube Heat Exchanger

,

2 PASSES TEMA Heat Exchanger

,

TEMA shell & tube heat exchanger

Tube:
ASME SA179(MIN)
Tubesheet, Stationary:
ASME SA516 GRADE70
Channel Or Bonnet:
ASME SA516 GRADE70
Channel Cover:
ASME SA516 GRADE70
Tube Bundle:
U BEND TUBE
Pass:
2 PASSES
Code Requirements:
TEMA Type AEU Or BEU. Can Meet TEMA “B”, “C” And “R”, ASME Section VIII Div. 1 And ASME Section III “N” Stamp.
Product Description

ASME U Stamp Certified 2 Pass TEMA Exchanger U-Bend Design for Thermal Expansion Resistance



Yuhong ASME VIII Div 1 Heat Exchanger:​​ A robust pressure vessel compliant with stringent ASME standards. Features critical components like Shell & Shell Cover, Channel/Stationary Head, Floating & Stationary Tube Sheets, Straight and U-Tubes for heat transfer, Transverse/Longitudinal Baffles for flow optimization, tie rods, expansion boughs, saddles, safety nozzles, and specialized impingement baffles and floating head assembly for reliability and efficiency.



Shell and Tube Heat Exchanger Typical parts and connections

  1. Shell
  2. Shell cover
  3. Shell flange (channel end)
  4. Shell flange (cover end)
  5. Shell nozzle or branch
  6. Floating tube sheet
  7. Floating head cover
  8. Floating head flange
  9. Floating head gland
  10. Floating head backing ring
  11. Stationary tube sheet
  12. Channel or stationary head
  13. Channel cover
  14. Channel nozzle or branch
  15. Tube (straight)
  16. Tubes (U-type)
  17. Tie rods and spacers
  18. Transverse (or cross) baffles or support plates
  19. Longitudinal baffles
  20. Impingement baffles
  21. Floating head support
  22. Pass partition
  23. Vent connection
  24. Drain connection
  25. Instrument connection
  26. Expansion bellows
  27. Support saddles
  28. Lifting lugs
  29. Weir
  30. Liquid level connection

Shell and Tube Heat Exchanger Tube Passes

a, square, When the shell side fluid is fouling and mechanical cleaning is required(tube pitch,in eg. 1inch, 1 1/4 inch)

b, triangular, When the shell side fluid is clean(tube pitch eg. 15/16, 1inch)

c, rotated square, When higher turbulence is required i.e. when Reynolds Number is low (< 2000)



Shell and Tube Heat Exchanger Baffle Type

a, cut-segmental baffle

b, disc and doughnut baffle

c, orifice baffle



Shell and Tube Heat Exchanger Structural Classification

├── Tubular

      ├── Double pipe

      └── Shell & tube

                                   ├── Fixed tubesheet

                                   ├── U-tube

                                   └── Floating head



OTHER TYPES OF HEAT EXCHANGERS

Gasketed / Welded plate and frame heat exchanger

Spiral heat exchanger

Tubular heat exchanger

Plate coils heat exchanger

Scraped surface heat exchanger
