Yuhong Floating Head Shell and Tube Heat Exchanger
Ideal for Heavy Fouling & Large Temperature Difference Applications
Floating head shell and tube heat exchangers are specially designed to solve problems of severe fouling, large temperature differences, and high maintenance requirements in industrial processes. As one of the most versatile and reliable heat exchanger types, they are widely applied in oil & gas, refinery, petrochemical, power generation, metallurgy, and large-scale chemical processing. Yuhong provides professional design, manufacturing, installation, and after-sales service for floating head heat exchangers, helping customers achieve stable, efficient, and long‑life heat transfer.
Product Overview
Yuhong floating head heat exchangers consist of a shell, fixed tube sheet at one end, floating tube sheet at the other end, floating head cover, tube bundle, baffles, and shell channels. The key feature is that one end of the tube bundle is not fixed to the shell, allowing free thermal expansion and contraction. This structure completely eliminates thermal stress caused by large temperature differences between shell side and tube side fluids.
Compared with fixed tube‑sheet and U‑tube types, floating head heat exchangers allow the entire tube bundle to be pulled out for mechanical cleaning on both shell side and tube side. This makes them the best choice for fluids that tend to form heavy fouling, scale, or sediment.
Main Technical Parameters
| Parameter |
Standard Specification Range |
Yuhong Customization & Service |
| Type |
Floating Head Shell and Tube Heat Exchanger |
Custom design for your process conditions |
| Design Pressure |
0.1 - 30 MPa |
High‑pressure reinforced structure available |
| Design Temperature |
-100℃ - 550℃ |
Adapt to high‑temperature and cryogenic systems |
| Shell Material |
Carbon Steel, Alloy Steel, SS304, SS316L, Duplex Stainless Steel |
Selected based on medium corrosion |
| Tube Material |
Stainless Steel, Carbon Steel, Titanium, Copper‑Nickel Alloy, Nickel Alloy |
Custom material for corrosive or high‑temp media |
| Heat Exchange Area |
5 - 3000 ㎡ |
Fully customized to thermal duty |
| Tube Diameter |
Φ19*2, Φ25*2.5, Φ38*3 mm |
Optimized for heat transfer and flow |
| Tube Length |
1m - 12m |
Adjustable to installation space |
| Passes |
1, 2, 4, 6 passes |
Optimized for flow velocity and efficiency |
| Connection Standards |
ANSI, GB, DIN, JIS |
Match your pipeline flange standard |
| Applicable Media |
Oil, gas, steam, water, chemical fluid, heavily fouling liquid |
Suitable for high‑fouling and high‑scaling media |
Key Advantages
Free Thermal Expansion
The floating head structure allows the tube bundle to expand and contract freely, completely eliminating thermal stress, making it perfect for large temperature difference working conditions.
Excellent for Heavy Fouling Fluids
The entire tube bundle can be easily pulled out, enabling thorough mechanical cleaning and descaling on both tube side and shell side, greatly reducing downtime and maintenance cost.
High Structural Stability
Reinforced tube sheets, robust baffles, and reliable floating head sealing ensure stable operation even under high pressure, large flow, and long‑term continuous working conditions.
High Heat Transfer Efficiency
Optimized baffle design and tube arrangement improve turbulence and heat transfer coefficient, reducing energy consumption and operating cost.
Wide Applicability
Suitable for almost all types of fluids, including clean, fouling, corrosive, high‑temperature, high‑pressure, and volatile media.
Safe and Reliable Sealing
Professional sealing structure at the floating head prevents internal and external leakage, ensuring safe and stable operation.
Yuhong One‑Stop Full‑Cycle Services
Custom Engineering & Thermal Design
Yuhong's professional engineering team provides full thermal and hydraulic calculation based on your actual parameters:
- Flow rate
- Inlet and outlet temperature
- Operating pressure
- Medium properties
- Fouling characteristics
- Installation space
We deliver the most efficient, reliable, and cost‑effective floating head heat exchanger solution.
Precision Manufacturing & Strict Quality Control
From raw material inspection to finished product testing, Yuhong implements full‑process quality management. Each unit undergoes:
- Hydrostatic pressure test
- Air tightness test
- Dimensional inspection
- Non‑destructive testing (NDT) if required
All products meet international standards such as GB, ASME, and DIN.
Tube Bundle Production & Replacement Service
We independently produce high‑precision tube bundles for floating head heat exchangers and provide tube bundle replacement, retrofit, and upgrade services for old equipment.
On‑Site Installation, Commissioning & Training
Yuhong provides on‑site installation guidance, equipment commissioning, operation training, and technical documentation to ensure smooth startup and stable performance.
Long‑Term After‑Sales Support
We offer:
- Regular maintenance and inspection
- Troubleshooting and emergency service
- Spare parts supply
- 24‑hour technical support
Helping you maximize equipment lifespan and minimize operational risk.
Conclusion
Yuhong floating head shell and tube heat exchangers are the optimal solution for industrial processes with heavy fouling, large temperature differences, and high reliability requirements. With mature design, stable quality, high efficiency, and easy maintenance, they are widely trusted by customers in petroleum, chemical, power, metallurgy, and other industries.
Whether you need a standard model or a fully customized floating head heat exchanger, Yuhong has the professional capability to support your project. Contact us with your process parameters, and we will provide a complete technical proposal, performance datasheet, layout drawing, and formal quotation.
