Name: ASME SA209 / SA209M Gr.T1A Alloy Steel Seamless Tube Boiler Tube For Boiler,Superheater,Reheater
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: ASME SA209 / SA209M
Availability: InStock

Home > Products > Boiler Tube >

ASME SA209 / SA209M Gr.T1A Alloy Steel Seamless Tube Boiler Tube For Boiler,Superheater,Reheater

ASME SA209 alloy steel boiler tube

seamless boiler tube for superheater

SA209M Gr.T1A reheater boiler tube

Place of Origin:

China

Brand Name:

YUHONG

Certification:

ISO 9001/TUV/PED

Model Number:

ASME SA209 / SA209M

Chat Now

Request A Quote

Product Details

Standard:

ASME SA209 / SA209M

Material Grade:

Gr.T1A

Form:

Seamless Tube

Diameter:

12.7 ~ 127 Mm (1/2 ~ 5 In)

Wall Thickness:

0.9 ~ 12.7 Mm (0.035 ~ 0.500 In)

Applications:

Boilers, Heat Exchangers, Superheaters, HRSG

Highlight:

ASME SA209 alloy steel boiler tube

seamless boiler tube for superheater

SA209M Gr.T1A reheater boiler tube

Payment & Shipping Terms

Minimum Order Quantity

500 KGS

Price

Negotiable

Packaging Details

Steel frame wooden case with plastic cap

Delivery Time

Depends on order quantity

Payment Terms

T/T, L/C at sight

Supply Ability

1000 TONS / month

ASME SA179 A179 Carbon Steel Seamless Tube Heat Exchangers For Oil Refineries, Condensers For Chemical Plants, Power Plants

Chat Now

ASME SA192 Seamless Carbon Steel Pipe High Strength Boiler Tube for Overheater And Water Wall

Chat Now

ASTM A213 T5 Alloy Steel Seamless Tube,Boiler Tube,Low Alloy High Strength Steel

Chat Now

ASTM A213 T9 Alloy Steel Seamless U Bend Tube Boiler Tube High Temperature Resistance

Chat Now

+8613625745622

nirit@steelseamlesspipe.com

0086-574-88013900

Chat Now

Product Description

ASME SA209 / SA209M Gr.T1A Alloy Steel Seamless Tube Boiler Tube For Boiler,Superheater,Reheater

ASME SA209 Gr.T1A is a seamless carbon-molybdenum alloy steel tube conforming to ASME standards, primarily used for high-temperature pressure components in boilers and superheaters.

A key characteristic of this material is the addition of molybdenum, which enhances its strength and creep resistance at high temperatures, making it superior to ordinary carbon steel.

This steel tube is mainly used in critical components of power plant boilers, such as water-cooled walls, superheaters, and reheaters.

Comparison Item	ASME SA209 T1a	ASME SA209 T1 / T1b
Primary Alloying Elements	C-Mo (Carbon-Molybdenum)	C-Mo (Carbon-Molybdenum); the three grades differ mainly in carbon content range
Tensile Strength (≥)	415 MPa	T1: 380 MPa / T1b: 365 MPa
Applicable Temperature Range	Suitable for service up to approx. 455°C	Suitable for service up to approx. 455°C
Key Advantage	Cost-effective, workhorse material for moderate temperature conditions	–
Typical Applications	Low-temperature superheater, reheater, water wall tubes	Similar to T1a

Chemical Composition
Element	Composition (wt%)
Carbon (C)	0.15 – 0.25
Manganese (Mn)	0.30 – 0.80
Phosphorus (P)	≤ 0.025
Sulfur (S)	≤ 0.025
Silicon (Si)	0.10 – 0.50
Molybdenum (Mo)	0.44 – 0.65

Mechanical Properties
Property	Value
Tensile Strength	≥ 415 MPa
Yield Strength	≥ 255 MPa
Elongation (in 2 in.)	≥ 30%

Application:

Boilers, as core pressure-bearing components in power plants and industrial boilers, such as water-cooled walls, economizers, and headers, are used for their primary applications as specified in standards.

Superheaters: Used to heat saturated steam into superheated steam; this is one of the key applications of T1a material, especially suitable for low-temperature superheater components in high-temperature sections.
Reheaters: Used to reheat steam that has already undergone work, improving circulation efficiency; this is also an important application of T1a tubes.
Heat Exchangers: Can be used in various industrial heat exchangers for heat exchange.
Process Furnace Tubes: Used in tubular furnaces in oil refineries to transport high-temperature process media.
