Name: SA179 Carbon Steel Embedded G Finned Tubes for Industrial Air Coolers in Power Industry
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: Embedded G Finned Tubes
Availability: InStock

Home > Products > Fin Tube >

SA179 Carbon Steel Embedded G Finned Tubes for Industrial Air Coolers in Power Industry

SA179 carbon steel finned tubes

industrial air cooler fin tubes

power industry finned tubes

Place of Origin:

China

Brand Name:

YUHONG

Certification:

ISO 9001-2015,etc.

Model Number:

Embedded G Finned Tubes

Chat Now

Request A Quote

Product Details

Product:

Finned Tubes

Finned Tubes Type:

Embedded G Finned Tubes

Embedded G Finned Tubes Material:

SA179 Carbon Steel Seamless Base Tubes With AL Fins

Embedded G Finned Tubes Length:

For Air Coolers, 9144MM Normally, Depend By Customers

Embedded G Finned Tubes Application:

Industrial Air Coolers, Heat Exchangers Tube Bundles, Condensers, Air Preheaters, And Waste Heat Recovery Units, Etc.

Embedded G Finned Tubes Industries Populares:

Power Generation, Petrochemical, HVAC & Refrigeration, General Industry

Highlight:

SA179 carbon steel finned tubes

industrial air cooler fin tubes

power industry finned tubes

Payment & Shipping Terms

Minimum Order Quantity

500Kgs

Price

Depend

Packaging Details

Poly Wooden Case With Iron Frame

Delivery Time

30-45 days

Payment Terms

T/T,L/C

Supply Ability

Depend

SA179 Carbon Steel Wound KL Finned Tubes for Industrial Air Coolers in Power Generation

Chat Now

HFW Finned Tube Serrated Type SA387 Grade 12, 13CrMo4–5 Fins for Power Plant HRSG

Chat Now

ASME SA179 Carbon Steel Tube with Aluminum Fins Extruded Fin Tube for Air Cooled Heat Exchangers

Chat Now

ASME SA192 Base Tube with Carbon Steel Fins Serrated Fin Tube for HRSG

Chat Now

008-574-88013900

market@steelseamlesspipe.com

008-574-88013900

Chat Now

Product Description

SA179 Carbon Steel Embedded G Finned Tubes for Industrial Air Coolers in Power Industry

Industrial air coolers play a crucial role in the power industry, mainly used for equipment cooling and energy conservation.Compared with traditional water - cooling systems, air coolers do not require a large amount of water resources, reducing water waste and environmental impact. Its structural components include finned tube bundles, the core components determining heat transfer efficiency. The finned tube structure enlarges the heat transfer area, thereby enhancing the heat exchange performance.

In industrial air cooler applications, the mainstream finned tube types cover wound finned tubes as well as embedded finned tubes.

Wound G Finned Tubes Advantages

High Heat Transfer Efficiency: Wound G fins are tightly and evenly wrapped around the base tube with a spiral structure, which maximizes the effective heat transfer area under the same tube length. The G-shaped fin profile optimizes air flow field distribution, reduces air side resistance, and enhances the convective heat transfer coefficient between fins and cooling air.
Excellent Structural Stability & Connection Tightness:The winding process ensures tight bonding between G fins and the base tube, with no obvious gap at the contact interface. This avoids heat transfer resistance caused by loose connection, and effectively prevents fin detachment or loosening during long-term high-temperature, high-velocity air operation.
Strong Corrosion & Wear Resistance:Wound G finned tubes can be processed with surface anti-corrosion treatments (such as galvanizing, epoxy coating) according to industrial media requirements.
Optimized Energy-saving Performance: The reasonable G-shaped fin profile reduces air side pressure drop, which can decrease the power consumption of axial flow fans in industrial air coolers while ensuring heat transfer effect.

A179 Base Tube Specifications

Chemical Composition

Carbon %	Manganese %	Phosphorus %	Sulfur %
0.06-0.18	0.27-0.63	0.035	0.035

Mechanical Properties

Tensile Strength, min	Yield Strength, min	Elongation in 2" or 50mm, min	Hardness Number max
47ksi (325 MPa)	26ksi (180 MPa)	35%	72 HRB

Fin Material Options

Aluminum

Common grades include Alu.1100 and Alu.1060. Light weight and high thermal conductivity, suitable for low-temperature industrial cooling scenarios

Carbon Steel

Low cost, applicable to dry, non-corrosive industrial air cooler working conditions (e.g. ordinary power plant cooling systems).
