ASME Certificated Tovwer OVHD Trim Condenser for Crude distillation unit

Place of Origin: CHINA
Brand Name: YUHONG
Certification: ASME U STAMP
Model Number: Regeneration Column
Minimum Order Quantity: 1 set
Price: negotiate
Packaging Details: EXPORT STANDARD
Delivery Time: 90 - 180 days
Payment Terms: L/C, T/T
Supply Ability: 1000 SETS PER YEAR
Inquiry Now
Get A Quote
Specifications
Highlight Features

ASME certified overhead trim condenser

,

crude distillation unit condenser

,

pressure vessel overhead trim

Certifications:
ASME U Stamp, National Board R Stamp
PLUG:
SB366 N04400
NUT:
SB164 N04400
BOLT:
SB164 N04400
WASHER:
MONEL
Product Description

ASME Certificated Tovwer OVHD Trim Condenser for Crude distillation unit.



YUHONG ASME-certified Tower OVHD Trim Condenser​ is a critical heat exchange equipment designed for crude oil distillation units, engineered to ensure efficient heat recovery and operational reliability under stringent industrial conditions.



Design & Configuration

The condenser adopts an AES-HORZ (Horizontal Fixed Tube Sheet)​ design, optimized for thermal efficiency and structural stability. Key dimensional parameters include:
  • Nominal Size: ∅1100 (Inner Diameter) × 4500 mm (Length).
  • Tube Details: 1092 tubes with a size of ∅20×1.8 mm, arranged in a 45° tube pattern​ with a pitch of 26 mm. The tube bundle length is 4500 mm, and the total heat transfer surface area reaches 308.0 m².
  • Flow Arrangement: 1 shell pass and 6 tube passes, paired with SEGM vertical-cut baffles​ (220 mm spacing, 17 pcs) ​

Material Selection & Corrosion Protection

  • Shell/Heads/Nozzles/Baffles/Tubesheet/Flanges: SA 516 Gr.70 + 2mm cladded with SB 127 (for shell, heads, nozzles, baffles, tubesheet) and SA 105 (tube-side flanges) / SA 106 (shell-side nozzles) – all with 2mm SB 127 cladding.
  • Channel: SA 516 Gr.B (with 3 mm corrosion allowance).
  • Tubes: SB 165 (corrosion allowance: 0, as internal/external conditions allow).
  • Supports: SA 36 (carbon steel, suitable for structural support).

​ASME Certificated Tovwer OVHD Trim Condenser for Crude distillation unit 0
