ASME-Certified Jacketed Process Vessel

Engineered for precise thermal control in mixing and reaction applications

Yuhong Holding Group: Building the Core of Your Process Line

At Yuhong Holding Group, we transform process requirements into reliable, certified industrial equipment. Our expertise includes fabrication of custom ASME pressure vessels, including critical jacketed reactors and mixers, designed to perform under exacting thermal and mechanical conditions. We support every project with comprehensive engineering and component supply.

Engineered Solution: The Jacketed Reactor Vessel

A jacketed reactor vessel provides fundamental temperature management for processes demanding accurate thermal control. This design incorporates a secondary containment layer—the jacket—encasing the primary vessel wall. By circulating heating or cooling media through this enveloping channel, the system achieves uniform thermal transfer to the vessel's contents, which is essential for consistent product quality, reaction efficiency, and process safety.

Design Anatomy & Engineering Rationale

Structural Feature	Typical Construction	Engineering Purpose & Client Benefit
Dual-Wall Cylindrical Body	Inner Shell & Outer Jacket from SA516 Gr.70	Creates the sealed annulus for thermal media. The jacket absorbs pressure stress, allowing the inner shell to be optimized for product compatibility.
Thermal Media Manifold	Dedicated Forged Nozzles (SA105) on Jacket	Enables efficient inlet/outlet of steam, coolant, or thermal oil. Proper sizing minimizes pressure drop in the jacket circuit.
Process Interface Head	Dished Head (SA516) with Multiple Nozzles	Consolidates all process connections (agitator, manway, inlet/outlet, instruments) on the top head, simplifying piping and maintenance access.
Integrated Agitation System	Shaft, Impeller, Mechanical Seal, & Drive	Induces mixing for homogeneity, heat transfer, and suspension. The seal system is selected for pressure, temperature, and sterility requirements.
Structural Support System	Skirt, Legs, or Lugs	Transfers operational loads (weight, wind, seismic) to the foundation. Design prioritizes stability and minimal stress on vessel walls.

Strategic Advantage of Jacketed Design

Selecting a jacketed vessel over alternative heating methods (like internal coils) is often a strategic decision for scalability and safety.

Scalability & Consistency: The jacket provides a large, consistent heat transfer area that scales efficiently with vessel volume, avoiding hot spots and ensuring batch-to-batch uniformity.
Inherent Process Safety: By isolating the energy source in the external jacket, the design eliminates direct contact with sensitive, volatile, or viscous process materials.
Operational Efficiency & Cleanability: Well-designed jackets allow for rapid heating/cooling cycles, while smooth internal surfaces are easier to clean and validate for pharmaceutical or food processing applications.

Project Value & Customization Scope

Risk Reduction via Certification: As an ASME U Stamp holder, we provide full code compliance, documented material traceability, and a Manufacturer's Data Report to reduce regulatory and insurance risk.
Configuration Built for Your Process: Every vessel is customized based on agitation needs, heating/cooling duty, pressure/temperature profiles, and cleanability standards.
Focus on Total Cost of Operation: Robust design prioritizes long service life and low maintenance, with full-diameter manways facilitating easy inspection and reducing downtime costs.

Initiate a Feasibility Discussion

To explore how a jacketed reactor can enhance your process reliability and efficiency, contact our engineering team. Forward your key process parameters to jimmy@steelseamlesspipe.com to begin a technical dialogue and receive a concept-level proposal.
